    Plain Weave Style and Stainless Steel Wire,316,304,304L,ss302,316L Material 1000 micron filter mesh

     |  0:Inquiry  |  0:Orders
    $1.00 / Roll|5 Rolls(Min. Order)
    Shipping:
    Support ExpressAir freightLand freightSea freight
    Customization:
    Logo Function Packaging Graphic OEM
    Target Price:
     USD / Piece
    Quantity:
     Rolls (Min. Order)
    Lead Time:
    Ship in  day(s) after supplier receives the payment
    Request Details:
    Leave Messages.
    Custom Request
    Send Inquiry

    Category

  • Architectural Mesh
  • Engineering Materials
  • Fence
  • Livestock
  • Mining Mesh
  • Processed
  • Quarry Screen Mesh
  • You May Like

    YHY Wire Mesh
    Chat now
    • Product Details
    • Buyer Reviews (0)
    • FAQ (6)
    Overview
    Quick Details
    Place of Origin:
    Hebei&China
    Port:
    Tianjin
    Brand Name:
    OEM
    Design:
    Customized Designs

    Packaging&Delivery

    Selling Units:
    Single item
    Single package size:
    1000 cm³
    Single gross weight:
    25 kg
    Package Type:
    aaaaa
    Lead Time:
    Ship in 10 day(s) after supplier receives the initial payment
    Product Description

    Plain Weave Style and Stainless Steel Wire,316,304,304L,ss302,316L Material 1000 micron filter mesh

    Stainless steel is selected for their wear-resisting, heat-resisting, acid-resisting and corrosion resisting characteristics. Many different grades of stainless are used in wire cloth.T304 is the most common, but other are used in specific applications to take advantage of each grade’s unique properties. The wire mesh made of stainless steel is extensively used in mining, chemical industry, food industry and pharmaceutical industry.

    Plain Weave Style and Stainless Steel Wire,316,304,304L,ss302,316L Material 1000 micron filter mesh

    1.Plain Weave: also called tabby weave, linen weave or taffeta weave, is the most basic type of weaves. In plain weave, the warp and weft are aligned so they form a simple cross-cross pattern. Each weft thread crosses the warp threads by going over one, then under the next, and so on. The next weft thread goes under the warp threads that its neighbor went over, and vice versa.

    Stainless Steel Woven Wire Mesh(Plain Weave)
    mesh/inch wire diameter(mm) aperture(mm) mesh/inch wire diameter(mm) aperture(mm)
    2 mesh 1.80 10.90 60mesh 0.15 0.273
    3 mesh 1.60 6.866 70mesh 0.14 0.223
    4 mesh 1.20 5.15 80mesh 0.12 0.198
    5 mesh 0.91 4.17 90mesh 0.11 0.172
    6 mesh 0.80 3.433 100mesh 0.1 0.154
    8 mesh 0.60 2.575 120mesh 0.08 0.132
    10mesh 0.55 1.990 140mesh 0.07 0.111
    12mesh 0.50 1.616 150mesh 0.065 0.104
    14mesh 0.45 1.362 160mesh 0.065 0.094
    16mesh 0.40 1.188 180mesh 0.053 0.088
    18mesh 0.35 1.060 200mesh 0.053 0.074
    20mesh 0.30 0.970 250mesh 0.04 0.061
    26mesh 0.28 0.696 300mesh 0.035 0.049
    30mesh 0.25 0.596 325mesh 0.03 0.048
    40mesh 0.21 0.425 350mesh 0.03 0.042
    50mesh 0.19 0.318 400mesh 0.25 0.0385

    2.Twill Weave:  In a twill weave, each weft or filling yarn floats across the warp yarns in a progression of interlaces to the right or left, forming a distinct diagonal line. This diagonal line is also known as a wale. A float is the portion of a yarn that crosses over two or more yarns from the opposite direction.

    Stainless Steel Woven Wire Mesh(Twil Weave)
    mesh wire diameter(mm) Material(AISI) Material(AISI)
    250 mesh 0.040mm 0.063 304 or 316
    300 mesh 0.040mm 0.044 304 or 316
    325 mesh 0.035mm 0.043 304 or 316
    350 mesh 0.030mm 0 .012.333342 304 or 316
    400 mesh 0.030mm 0.033 304 or 316

    3. Plain Dutch Weave: similar with plain weave, just the weft and warp wire have different wire diameter and different mesh size.
    4. Twill Dutch Weave: similar with twill weave, just the weft and warp wire have different wire diameter and different mesh size.
    5. Reversed Dutch Weave: difference from standard Dutch weave lies in the thicker warp wires and less weft wires.

    Stainless Steel Woven Wire Mesh(Dutch Weave)
    Mesh Wire Dia.(mm)

    material(AISI)

    12mesh x64mesh 0.58/0.40 304 or 316
    24 Mesh x 110 Mesh 0.36/0.25 304 or 316
    14 Mesh x 88 Mesh 0.50/0.33 304 or 316
    30 Meshx 150Mesh 0.18/0.14 304 or 316
    40 Mesh  x 200Mesh 0.14/0.11 304 or 316
    50 Mesh  x 250Mesh 0.10/0.071 304 or 316
    80Mesh x700Mesh 0.06/0.05 304 or 316
    165Mesh x800Mesh 0.071/0.040 304 or 316
    165Mesh x1400Mesh 0.05/0.032 304 or 316
    200Mesh x1800Mesh 0.05/0.03 304 or 316
    325Mesh x2300Mesh 0.030/0.025 316L
    400Mesh x2800Mesh 0.030/0.02 316L

    Plain Weave Style and Stainless Steel Wire,316,304,304L,ss302,316L Material 1000 micron filter meshPlain Weave Style and Stainless Steel Wire,316,304,304L,ss302,316L Material 1000 micron filter mesh

    Knowledge of Stainless Steel Material
    1. Mesh Count = 25.4mm/D+A
    2. Aperture= 25.4mm/Mesh count - Diameter
    3. % Open Area= A/(A+D)² X 100%
    4. Micron= Aperture(mm) X 1000
    5.Mesh - The number of openings per lineal inch.
    6.Aperture- The distance between two adjacent wires
    7.Diameter- The thickness of the wire before weaving
    8.% Open Area- The ratio of the area of the aperture to the area of the 9.mesh expressed in percentage terms
    10.Warp- All wires running lengthwise of the cloth as woven
    11.Weft- All wires running across the cloth as wovenPlain Weave Style and Stainless Steel Wire,316,304,304L,ss302,316L Material 1000 micron filter mesh

    Our factory have been passed the Bureau VERITAS certificated: ISO 9001: 2015 and CE certificate. We have cooperated with China big steel factory for 20 years, our steel raw material quality meets the international standard. We also can offer difference steel raw material test report.



    YHY products have been exported to 50 courtiers and area. Now our sales department have a completely sales system, we offer customers price within 8 hours, and make samples within 5 days.



    YHY People always making efforts to improve our technical and develop new products. Our target is to be the top one of metal wire mesh industry in China within 5 five years and make our customer’s satisfactions be 100%.

    Plain Weave Style and Stainless Steel Wire,316,304,304L,ss302,316L Material 1000 micron filter mesh

     Materials: 1.AISI:   AISI 304,AISI 304L,AISI 316,AISI 316L

                           2.T series:      T 304,T 316

                           3.SS series:    SS 410, SS 430, SS 302

                           4.SUS :           SUS 310,SUS 310L

    Width: 0.914m, 1m, 1.22m, 1.3m, 1.4m, 1.5m, 1.6m, 2m, 3m, 4m, 6m.



    Roll Length: 30m,30.48m or as per your request

    Plain Weave Style and Stainless Steel Wire,316,304,304L,ss302,316L Material 1000 micron filter meshPlain Weave Style and Stainless Steel Wire,316,304,304L,ss302,316L Material 1000 micron filter mesh 1. Are you a manufacturer?
     Yes, we are the ISO and CE certificated Manufacturer and our factory founded in this industry since 1989.

    2. Will your price competitive?
     Yes , we have stable and large raw material supplier ,we work with them for nearly 20 years .   Our machine and technical it is most advanced , we will send our technical to aboard to learning new technical every year.

    3.Can we have a sample ?
    Yes , if the samples it is not much big , we can offer free sample , the courier it is paid by customers.

    4.Can we visit your factory ?
    Yes , you are welcome to visit us . we can pick you up from the airport .

    5. What are the payment terms?
    We can accept TT , LC , West Union , Money Gram , Cash .

    Plain Weave Style and Stainless Steel Wire,316,304,304L,ss302,316L Material 1000 micron filter mesh
