Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence

  • Customization

  • Share:
    | Favorite (0)
    FOB Price:
    $ 24.80 $ 27.80
    Min. Order:
    ≥ 50 Rolls
    Reviews:
     |  0:Inquiry  |  0:Orders
    Shipping:
    Support Express · Sea freight · Air freight · Land freight
    Customization:
    Logo Function Packaging Packaging OEM
    Target Price:
     USD / Piece
    Quantity:
     Rolls (Min. Order)
    Lead Time:
    Ship in  day(s) after supplier receives the payment
    下单前请务必先和商家洽谈以上信息,按双方约定填写. Leave Messages.
    Custom Request
    Send Inquiry
    Seller Services:
    Quick replyOEMQuality SafetyDesign Confidentiality

    最新产品

    YHY Wire Mesh
    Chat now
    • Product Details
    • Buyer Reviews (0)
    • FAQ (6)
    Overview
    Quick Details
    Place of Origin:
    Hebei&China
    Port:
    Tianjin
    Brand Name:
    OEM
    Design:
    Customized Designs

    Packaging&Delivery

    Selling Units:
    Single item
    Single package size:
    1000 cm³
    Single gross weight:
    25 kg
    Package Type:
    aaaaa
    Lead Time:
    Ship in 10 day(s) after supplier receives the initial payment
    Product Description
    Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence



    Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence



    Hinge Joint Fencing

    The hinge joint knots also called field fence ,grassland fence, cattle wire fence .The hinge joint knot is found on both galvanized low carbon and high tensile wire products.

    This is the most common knot in agricultural fencing. The knot is formed by wrapping the vertical stay wire pieces around the line wire at each intersection. This design can also absolve animal impact without damage and is the most economical knot choice available. Besides, they also can be used with barbed wire or chicken wire for farm fencing, garden fencing, road fencing, forest fencing and so on.







    1. Product Description





     The livestock wire fence made by mild steel wire and high tensile steel wire.The hinges joint knots is the most common knot in agricultural fencing. The knot is formed by wrapping the vertical stay wire pieces around the line wire at each intersection. This design can also absolve animal impact without damage and is the most economical knot choice available.

    Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence



    Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence



      Specification:     .

    Hinge Range 0.6 to 2.45 meter available
    Vertical wire distance 50, 100,150,200,250,300  350,400mm available
    Length 50 meter, 100 meters, and 150 meter
    Wire Material Finishing Hot-dip galvanized, Electro galvanized
    Material High-quality high carbon steel wire, low carbon steel wire
    Knot type tight lock knot type
    Main market Malaysia, Australia, Peru, North America, and Africa.





    There is difference steel wire material for you to choose .

     A. Hot dipped galvanized wire

     B. Heavy zinc coated wire

     C. Zinc aluminum alloy wire

     D. PVC coated wire

    Wire Material Difference Wire  Material  Cooperation
      Zinc coated Zinc Layer Use Life Price
    A 60g/mm2  35um   15years Competitive
    B 260g/mm2  150um   50years Higher
    C 260g/m2 +10%Alu  150um   50years   Expensive
    D Inner wire 20g/mm2 3um +1mm PVC layer  10years Only suitable for Edge wire





    The available wire for produce the wire fence it is : low carbon steel wire ,

    Carbon steel wire (hard type) , high carbon steel wire .

     Wire Material  Physical Properties
    Tensile Strength  Mpa Yield Strength Mpa Elongation % V-type shock absorption work (vertical) Ak/J
    low carbon steel wire 350--450 195 33 ≥27
    Carbon steel wire  550-750 225 37 ≥27
    high carbon steel wire  1200-1400 350 39 ≥27







     Product  Advantage

    Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence



    1) On the basis of the ordinary Field fence, an advanced pressure wave process is adopted, and one or two deep 12 mm wide and 40 mm bends are pressed on each mesh of the horizontal wire.T his kind of technology makes the mesh surface flatter and effectively enhances the elasticity of the mesh surface. It alleviates the deformation of the mesh surface caused by thermal expansion and contraction in areas with large climate change in winter and summer. Since the ripple increases the cushioning force of the mesh surface, the mesh surface can automatically return when the beast hits.



      Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence

    2)  The Stay wire and the Line wire can be adjusted.  It can make to be a few wires or more wires according to the farmland request.  For example, if your only for Person proof you just can choose the bigger line wire distance. If you need proof the small animals get through, then you can choose with more lines wire and the vertical wire distance can be smaller too.

    Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence

    3) The fence also can make custom sized, you can tell us your requirements then we can design the suitable fence for you. Please check the Photos it is the one we made for our customers from  New Zealand, they want the more strength of the edge wire, so we use the double wire to make the Edge of the field fence, it has more high tensile  avoiding  the animals attacked the fence.







    packaging and boxing

     Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence

    One roll finished then put the labels and tie the mesh with the binding wire . Our company have the designer department we can design for your labels for your package

    Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence



     After finish each roll then package by plastic film and package by pallets . The package can be made according to customer request , it can be package by pallets also can loading container by bulk .







     Our Company:





    Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence
    (1) Steel raw material suppliers from the big steel factory of China
    (2) 10 Welded machine import from Germany
    (3) Qualified and trained technical and workers
    (4) Strictly Quality Control Processing

    Anping YingHangYuan Metal Wire Mesh Co., Ltd. It is located in the largest wire mesh manufacture base in Asia, Anping County, Hebei, China. It has become a big comprehensive wire mesh company which is engaged in domestic and foreign trade. Since our international business department set up now our products are sold 50 countries and area, such as USA, Germany, Italy, Australia, and Southeast Asia etc.
    Our factory has been passed the Bureau Veritas certificated: ISO 9001: 2015 and CE certificate. We have cooperated with China big steel factory for 20 years, our steel raw material quality meets the international standard. We also can offer difference steel raw material test report.



    Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence

    Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence

    Hot dipped galvanized 2.0meter Height 100mm vertical wire distance 100m long field fence livestock hinge joint for farm fence
